ZM336AH Inline Router+Saw Blade PCB Depanelizer
Overview The SEPRAYS ZM336AH is an inline PCB depanelizer developed for automated SMT production. PCB panels enter through the loading conveyor and are transferred to the cutting worktable by a vacuum handling system. After vision alignment, the machine performs routing or saw-blade cutting according to the programmed cutting path. Once…
-
ZM300H Router+Saw Blade PCB Depanelizer
Overview The SEPRAYS ZM300H is an offline PCB depanelizer designed for PCB and PCBA panels with different connection structures. It combines independent router-bit and saw-blade cutting systems, allowing manufacturers to process irregular contours, straight cuts, mouse-bite tabs, V-cut grooves, and breakaway rails within one machine. For factories handling varied PCB…
-
ZM30-M Online Multi-tool PCBA Splitter
Overview The ZM30-M uses an upper circular blade and lower straight blade cutting structure. The upper circular blade travels along the preset V-groove while the lower blade supports the cutting line to complete straight PCBA separation. The manually controlled sliding mechanism gives the operator direct control over the cutting movement,…
-
ZM30-L Aluminum Substrate Depaneling Machine
Overview The ZM30-L separates pre-scored boards by guiding the V-groove into the circular-blade cutting path. The board moves along the guide while the lower circular blade drives the cutting action and the upper blade follows the groove. Dual-blade and six-blade versions are available for different board thicknesses, cutting requirements and…
-
ZM30-P Sickle PCB Board Machine
Overview The ZM30-P uses an upper-and-lower straight blade structure for linear PCB separation. The PCB is guided from the side so the V-groove enters the cutting position between the two blades. The blade assembly then separates the PCB along the required straight cutting line, providing a simple mechanical depaneling process…
-
ZM30 Moving Blade V-groove Depaneling Machine
Overview The ZM30 uses an upper circular blade and lower linear blade configuration. The PCB/PCBA panel is positioned on the lower blade, while the upper circular blade travels horizontally along the cutting line to separate the panel. The machine includes mechanical adjustment mechanisms for board positioning and cutting setup, making…
